Flaw detector 6200

Function and Features: High speed, high brightness, 640 * 480 high-resolution color display

Function and Features:
High speed, high brightness, 640 * 480 high-resolution color display, working normally under strong light, with one click operation, making the flaw detection very simple and fast. It includes an electronic manual to help guide the operation steps and understand the flaw detection method
One click operation for quick inspection, providing assistance information for inspection at any time
Automatically test probe zero point, sound velocity, and K value
Automatically create DAC and AVG curves
Automatic gain and search memory for the highest wave
Automatically display the location of defect echoes (horizontal, depth, distance, equivalent value)
Automatic gate sound and light alarm (door position, door width, door height can be freely adjusted)
Free switching of 200 sets of flaw detection channel technology
Free input of various industry inspection standards
Fully imported original motherboard components
Large capacity storage, 8000 pieces of flaw detection data space, no data loss after power failure
Long working time, no memory efficient lithium battery, continuous working time greater than 6 hours
Ethernet high-speed data transmission, browser can directly read and print flaw detection reports
Long term dynamic recording and storage of flaw detection waveforms
Channel password setting, flaw detection personnel can pre store their own flaw detection channels, permanently saved and not modified by others
Two way communication, users can edit their own flaw detection report format by themselves
Purpose:
This instrument can detect internal defects (such as cracks, inclusions, pores, etc.) and automatically locate, evaluate, and diagnose them.
Widely used in laboratories, special inspection institutes, shipbuilding, oil and gas equipment, aerospace, military, chemical, power, steel, metallurgy, railway, automobile manufacturing, machinery, boilers and pressure vessels, special equipment, petroleum pipelines, construction industry, mold manufacturing and other industries. We have rich experience in non-destructive testing of forgings, castings, plates, pipes, bars, and steel pipe alloy parts; Customers are distributed throughout the country, such as the National Special Inspection Institute, the National Steel Structure Testing Center, Shanghai Petroleum Machinery Manufacturing Company, Shanghai Wind Power Company, Zhejiang BYD Automobile Manufacturer, China Railway Administration, Xinjiang Petroleum Equipment Manufacturer, etc.
Technical parameters:
Frequency range: 0.4-20MHz
Gain range: 0-120dB, 0.1,2.0,6.0dB in steps
Dynamic range: 32dB
Vertical linearity:<3%
Horizontal linearity: 0 within 1m
Scanning range: 0.5-10000mm
Resolution:>40dB
Sensitivity margin:>62dB
Working mode: Single/Double, Penetrating
Pulse generator: Variable pulse generator
Damping: 50/100/400 Ω automatic matching
Detection method: Half wave/RF
Inhibition: 0~99% linear inhibition
Display ambient temperature: -20~50 ℃
Charger: 220~240V AC input
Working voltage: 7.4V ± 0.3V
Size: 215 * 175 * 33mm (length * width * thickness)
Weight: 1kg
Standard configuration:
Host 6200 1 unit
4 probes (1 straight probe and 1 oblique probe each)
4 probe wires
Two detachable polymer lithium batteries
1 charger
1 power connection cable
1 router
1 Ethernet cable
1 certificate of conformity
1 copy of instruction manual
1 instrument package
1 instrument box
1 instrument strap
Two copies of inspection documents
1 copy of packing list
