Electro hydraulic servo drive shaft fatigue test bench
NegotiableUpdate on 03/26
- Model
- Nature of the Manufacturer
- Producers
- Product Category
- Place of Origin
Overview
The fatigue test bench for electro-hydraulic servo drive shafts adopts a test platform structure and can be used for torsional fatigue testing and static characteristic testing of various heavy-duty vehicle drive shafts and half shafts
Product Details
Electro hydraulic servo drive shaft fatigue test bench
Adopting a test platform structure, it can be used for torsional fatigue testing and static characteristic testing of various heavy-duty vehicle transmission shafts and half shafts.
Technical Indicators:
Maximum static test torque:± 35000Nm, indication accuracy ± 1% (2-100% FS).
Maximum dynamic test torque:±25000Nm;
Maximum swing angle:±45°；
Test frequency:0.01-10Hz；
Main test waveforms: sine wave, triangular wave, square wave, oblique wave, etc;
