Intelligent wireless 4G data collector

1. Overview

The multi-channel intelligent wireless 4G data collector is a new series of ultra-low standby power data acquisition modules based on 2G/3G/4G networks from Shanghai LeZhen Detection Technology Co., Ltd. The data collection module integrates I/O and data collection in a single device, supports standard TCP protocol, and connects to the server through 2G/3G/4G network to achieve comprehensive functions such as data collection, storage, display, control, and alarm. The data acquisition module is an analog input module that can simultaneously sample 8 signals with a sampling accuracy of up to 16 bits.
Suitable for collecting various voltage and current signals, vibration signals, temperature signals, etc. from industrial sites.

2. Characteristics

32-bit ARM processor;
Embedded real-time operating system;
Communication network: 2G/3G/4G full network
Configuration method: Serial port configuration
Number of input channels: 8 signal inputs;
Input signal range; ± 10V, ± 5V, ± 20mA;
AD conversion resolution: 16 bits;
Sampling speed: 1~8K times/second (default configuration, full channel)
Each analog input channel can be independently enabled or disabled,
The measurement range and upper and lower limits can be independently configured;
1-channel digital output, collector open drain output;
Isolation withstand voltage: 2500 VDC;
Operating temperature range: -20 ℃ to+85 ℃;
Industrial grade casing, IP67 waterproof rating;
Ultra low power standby, standby current<200 microamperes (under 12V DC power supply conditions);
Power supply method: built-in 12V3A lithium battery; Rechargeable; Equipped with a dedicated 12V1A charger;

3. Hardware structure

Product schematic diagram:

Schematic diagram of panel interface:


Instructions for indicator light operation:
After pressing the switch, the indicator light will turn on and flash once every 2 seconds; The device automatically connects to the network, and the indicator light flashes once every second after connecting to the network. When the sensor data is uploaded on the mobile app, the indicator light flashes quickly.

4. System architecture diagram
